Mainly for magnetic ring products with multiple turns of fine wire, such as sensor coils, transformer coils, and leakage protector coils.
Product Features
This toroidal coil winding machine is specially designed for multi-turn thin wires. It truly realizes fully automatic feeding, automatic loading, automatic winding, and fully automatic unloading. One person can operate more than 20 machines without any downtime.
Save your labor costs, making fully automated products a reality.
From loading the magnetic core, wire feeding, winding, and unloading, it is fully automated and can wind the wire 360°
Toroidal (toroid) transformers use magnetic cores that have a toroidal (ring or donut) shape. They are passive electronic components, consisting of a circular ring or donut-shaped magnetic core of ferromagnetic material such as laminated iron, iron powder, or ferrite, around which wire is wound.
The use of toroidal-shaped cores has increased greatly because of their superior electrical performance. Because of its symmetrical design, the magnetic flux that leaks outside the core (leakage flux) is very low, therefore it is more efficient and thus radiates less electromagnetic interference (EMI).
Application areas
Mainly aimed at thin wire multi-turn magnetic ring products, such as sensor coils, transformer coils, and leakage protector coils.
Basic information about XINGTE
Experience
XINGTE was established in 2007, with more than 17 years R & D experience in the coil winding area
Plant Size
XINGTE is headquartered in Shenzhen, with a factory area of more than 30,000 square meters, which can ensure our Strong productivity
Service
XINGTE has more than 230 technical service and after-sales staff, worldwide service points worry-free after-sales service
Patents & certificates:
XINGTE obtained 120+ Patents and related certificates
Production Capacity
XINGTE has more than 600 experienced employees, which can guarantee our Production capacity and fast delivery
Technology
XINGTE has more than 130 experienced engineers, which can ensure our strong R & D ability, also can guarantee our customization capability
XINGTE PRODUCTION LINE
1, Motor stator, rotor, and other related coil winding machine
2, Transformer-related product coil winding machine
3, voice coil-related product winding machine
4, inductor coil winding machine and
5, customized fully automatic line for the motor, speaker, transformer production line
Product parameters
| Model number: | XT-HGQ05J |
| Wire Diameter : | 00.08 ~ 0.4mm |
| Coil O.D | 10-40mm |
| Coil I.D | 5-7 mm |
| Wire length | 100-2800mm |
| Winding speed | 1500RPM |
| working station: | 2 stations |
| Power: | 6KW |
| Power supply: | AC 220V,50/60Hz |
| Air pressure: | > 0.6Mpa |
| Machine dimension: | 900*1150*2000mm |
| G. W: | 400KGS |
